MSX emulator for the DS made by Popolon.

Unzip the archive and copy fmsxDS.nds on your flash card.
Copy the /msxds folder that contains 'CMOS.ROM' and 'Carts.crc' files into root of your flash card.
Copy MSX/MSX2/MSX2+ japanese BIOS, FM-PAC BIOS and Kanji ROM into this folder.
That is the following files:
• MSX.ROM = MSX BIOS and BASIC
• MSX2.ROM = MSX2 BIOS and BASIC
• MSX2EXT.ROM = MSX2 ExtROM
• MSX2P.ROM = MSX2+ BIOS and BASIC
• MSX2PEXT.ROM = MSX2+ ExtROM
• DISK.ROM = DiskROM and BDOS
• FMPAC.ROM = FMPAC BIOS
• KANJI.ROM = KANJI ROM (JIS 1st+2nd Class)
• A1WXKDR.ROM = Kanji Basic from FS-A1WSX
• CMOS.ROM = To save parameters of the MSX.

Correct BIOS for msxDS.
• for MSX 1 mode:
MSX.ROM = National CF-2000 or FS-4000 ROM (CRC32: EE229390 or 071135E0)
• for MSX 2 mode:
MSX2.ROM = National FS-4700 or FS-5000 ROM (CRC32: 9B3E7B97 or A44EA707)
MSX2EXT.ROM = National FS-4700 or FS-5000 ROM (CRC32: 4A48779C or 43E7A7FC)
• for MSX 2+ mode:
MSX2P.ROM = Panasonic FS-A1WX ROM (CRC32: 19771608)
MSX2PEXT.ROM = Panasonic FS-A1WX ROM (CRC32: B8BA44D3)
KANJI.ROM = Panasonic FS-A1WX ROM (CRC32: 1F6406FB)
A1WXKDR.ROM = Panasonic FS-A1WX Kanji Basic ROM (CRC32: B4FC574D)
• for PSG+FM sound mode:
FMPAC.ROM = Panasonic FM-PAC BIOS ROM (CRC32: 0E84505D)
• for Floppy Disk Drive emulation:
DISK.ROM = Panasonic FS-FD1a Floppy Disk Drive extension controller ROM (CRC32: 697EAF4E)
